1) IEEE802.3af/at/bt Standard
2) PoE :1,2+/3,6- 4,5+/7,8-
3) Power: 90 WattsMaximum
4) Input Power AC Input Voltage: 100~240VAC
5) PoE data & power transmission distance 100meter
6) Weight:400g , metal shell
7) Size:76*44*172mm
8) Support 10/100/1000/2500Mbps One Port
Feathers
l IEEE802.3af/at/bt Compliant
l PoE Pin:1,2+/3,6-;4,5+/7,8-
l Power:90 Watts
l Input Voltage: 100~240VAC
l Output Voltage: 54VDC~57VDC
l Support 10/100/1000/2500Mbps
l PoE data & power transmission distance 100meter
l Full Over-Voltage and Over-Current Protection;
l Compact size
l Metel housing
Mechanical Characteristics
- Length : 172.0mm(6.77inch)
- Width : 76.0mm(2.99inch)
- Height : 44.0mm(1.73inch)
- Weight : 660g(23.28oz)
Output
Applications
- IP Telephones
- Wireless Access Points
- Bluetooth Access Points
- Security Cameras
- IP Point Servers
- WiMAX Access Points
