POE SWITCH

250 Meter 4+2 Ports POE Switch 48V 10/100Mbps 2 Uplink Switch for Camera CCTV System｜X0402PE

Get A Quote
Contact Us
Product Name
100Mbps 4+2 ports POE Switch
Product Specifications
4*100M POE port+ 2 * 100M Uplink port
Total Power
65W (power built in)
Output Power
15.4W
Power Supply Standard
IEEE802.3AF/AT
Input Voltage
AC110-220V
Transmission Wire Core
1/2(+),3/6(-)
Network Standards
IEEE 802.3、IEEE 802.3U、IEEE 802.3X、IEEE 802.3AF、IEEE 802.3AT
Transmission Speed
6 port 10/100Mbp(sself-adaption)
Transmission Distance
100 meter/250 meter (setup)
Transmission Medium
Class 5 and above unshielded twisted-pair wire
Pass-through Mode
Store forward
Port Flip
Auto MDI/MDIX
Port Function
power supp'x oriorty mechanism, asd and ferwarding,MAC automatic learning and aging
Flow Control Mode
IEEE802.3X Full-duplex flow control and BACK PRESSURE half-duplex flow control
Pilot Lamp
Power supply indicator lamp,LINK/ACT indicator lamp
Working Temperature
-10°C~60°C
Appearance Material
Metal
Outline Dimension
190*125*38 mm
Product Weight
0.80KG(net weight)
