POE SWITCH

120W VLAN POE Switch with 8 Network Ports 10/100Mbps POE Switch Capacity 8+2 Uplink Ports IEEE802.3af/at Built-in Power Supply X0803PE

Get A Quote
Contact Us
Product Name
HL-X0803PE (100Mbps 8+2 ports POE Switch)
Product Specifications
8*100M POE port+ 2 * 100M Uplink port
Total Power
120w (power built in)
Output Power
15.4W
Power Supply Standard
IEEE802.3AF/AT
Input Voltage
AC100-240V
Transmission Wire Core
1/2(+),3/6(-)
Network Standards
IEEE 802.3、IEEE 802.3U、IEEE 802.3X、IEEE 802.3AF、IEEE 802.3AT
Transmission Rate
8 ports 10/100Mbp + 2 ports 10/100/1000Mbps adaptive
Transmission Distance
100 meter/250 meter (settable)
Transmission Medium
Class 5 and above unshielded twisted-pair wire
Pass-through Mode
Store and forward
Port Flip
Auto MDI/MDIX
Port Function
Power supp'x oriorty mechanism, asd and ferwarding,MAC automatic learning and aging
Flow Control Mode
IEEE802.3X Full-duplex flow control and BACK PRESSURE half-duplex flow control
Indicator Light
Power supply indicator lamp,LINK/ACT indicator lamp
Working Temperature
-20°C~60°C
Appearance Material
Metal
Outline Dimension
200*140*45 mm
Product Weight
0.80KG(net weight)
